Open Medical Electric Stretcher Ambulance
product detail
Advantages and Limitations:
Advantage: Open ambulances can be more cost-effective to manufacture and maintain compared to enclosed models. They may also offer better ventilation and visibility for the patient in certain situations.
Limitation: They provide less protection from the environment and external factors such as noise, dust, and extreme weather conditions. This can potentially disrupt patient care and comfort.
Uses:
Open ambulances are often used in areas where resources are limited or for specific types of emergencies where a more basic form of transport is sufficient.
They may also be used for transporting patients over short distances or in situations where speed is of the essence and the lack of full enclosure is not a major concern.
| Basic Parameter | Overall Dimensions (L*W*H mm) | 4650*1500*2050 | |
| Wheelbase (mm) | 2740 | ||
| Front/Rear Wheel Base(mm) | 1285/1325 | ||
| Tyre Specification | 165/70R13C | ||
| Curb Weight (kg) | 1390 | ||
| Number of Passengers (seats) | 6 | ||
| Car Body Structure | Fiberglass parts + aluminum profiles | ||
| Front and Rear Suspension Systems | Before: McPherson independent suspension Rear: Leaf spring non-independent suspension |
||
| Brake System | Front panel rear drum + hydraulic dual pipeline + vacuum power | ||
| Steering System | Double output steering machine + electric power | ||
| Drive System | Rear mounted rear wheel drive | ||
| Seat | Bus seats and armrests/leather seats and guardrail | ||
| Instrument Panel | Blister material | ||
| Paint | High quality paint + computer paint + professional spraying equipment | ||
| Electrical System | Battery | Category | Maintenance free battery |
| Quantity | 8 | ||
| Capacity | 6V200Ah（3hr） | ||
| Battery Voltage and Capacity (V/Ah) | 48/200 | ||
| Motor | Model Number | 48V | |
| Voltage and Power (V/kw) | DC48/5 | ||
| Rated Current (A) | 130 | ||
| Work System | S2-60min | ||
| Cooling Mode | Natural cooling | ||
| Controller | Category | AC asynchronous motor controller | |
| Model Number | MC3528 | ||
| Supply Voltage (V) | 48 | ||
| Maximum Output Current (A) | 350 | ||
| Charger | Model Number | 48V | |
| Input Voltage and Current (V/A) | AC220/≤11 | ||
| DC-DC Converter | Input Voltage (V) | 36-48V | |
| Output Voltage (V) | DC13.8 | ||
| Output Power (W) | 500 | ||
| Performance Parameter | Maximum Speed (km/h) | ≤30 | |
| Maximum Range (km) | ≥80 | ||
| Maximum Gradient (%) | ≥15 | ||
| Minimum Turning Radius (m) | ≤5.2 | ||
| Minimum Ground Clearance (mm) | ≥330 | ||
| Braking Distance (m) | ≤5 | ||
| Other | Medical Equipment | Self Retractable Stretcher | |
