New Energy 22 Seats Electric Sightseeing Bus Car With Closed Door

New Energy 22 Seats Electric Sightseeing Bus Car With Closed Door

The new energy 22 seats electric sightseeing bus car with closed door combines comfort, functionality, and environmental friendliness. It offers a quiet and smooth ride with zero emissions. Equipped with modern features, it provides a pleasant sightseeing experience for passengers.

Electrical System

Electric control	Curtis AC 96V
Battery	6v200ah / pcs, 16 pcs / 96V maintenance free battery
electric machinery	15kw AC motor
battery charger	Portable intelligent charger
Charging time	8-10 hours (80% discharge rate)

Body Configuration

Basic body color	White, green, yellow and blue (customized according to customer needs)
chair	Driver's single seat, opposite the rear seat
car body	Steel frame + FRP shell
Doors and windows	The main driver opens the door unilaterally, with aluminum alloy sliding toughened glass window on the top and transparent PC board on the bottom. A middle opening electric door on the right side of the vehicle
Instrument panel	Liquid crystal instrument (including current, voltage, vehicle speed, rotating speed, mileage, electric quantity, light signal, etc.)
Rearview mirror	One manual external rearview mirror on the left and right + internal rearview mirror
Lights and signals	Combined front lamp, combined rear tail lamp, side turn signal lamp, interior lamp, electric horn, reversing buzzer and reversing radar
sound	Car MP3, professional speaker
switch	Start switch, light and wiper combination switch, front and rear reversing, interior lamp, warning lamp and rocker switch of backup alarm
Frame	Steel frame, surface antirust treatment
Steering wheel	Polyurethane foam steering wheel
paint	Computer paint mixing, professional spraying equipment

Chassis

Power train	Stepless speed regulation system
steering system	Recirculating ball steering machine + directional assistance
Front axle and suspension	Leaf spring non independent suspension, cylindrical hydraulic damping
Rear axle and suspension	Full floating rear axle, leaf spring non independent suspension, cylindrical hydraulic damping
braking system	Front and rear drum hydraulic brake, dual circuit hydraulic brake, brake booster, parking brake device
tyre	Steel wheel hub / front and rear 165r13c vacuum radial tire

Technical Parameter

passenger	22 persons	Minimum ground clearance	150mm
LWH	5500×1700×2350mm	braking distance	≤7m
Vehicle equipment quality	1570kg	Charging input voltage	220v
Vehicle load	1650kg	Maximum travel speed	26km/h
Front and rear track width	1470/1470mm	Driving range (no load on level road)	100km
wheelbase	3100mm	Maximum climbing gradient	15%
Minimum turning radius	7m

Optional

Product Introduction

The new energy 22 seats electric sightseeing bus car with closed door is a cutting-edge vehicle designed to provide a comfortable and efficient sightseeing experience. This eco-friendly bus is powered by electric technology, producing zero emissions and reducing our carbon footprint.

Featuring 22 seating capacities, it offers ample space for a large group of passengers to enjoy the sightseeing journey comfortably. The closed door design provides added security and protection from the elements.

The electric motor ensures a quiet and smooth operation, creating a pleasant environment for passengers. With its advanced battery technology, this bus offers a long driving range, allowing you to cover more ground without the need for frequent charging.

Equipped with modern amenities, such as comfortable seating, air conditioning, and large windows, it ensures a comfortable and enjoyable ride for all. The interior is designed with passenger convenience in mind.

The bus is designed to handle various terrains and road conditions, providing a stable and safe driving experience. Its sleek and modern exterior adds a touch of style to the overall look.

Whether used for city tours, nature reserves, or tourist attractions, the new energy 22 seats electric sightseeing bus car with closed door offers a sustainable and convenient mode of transportation. It helps to reduce noise pollution and contributes to a cleaner and greener future.

This vehicle is not only reliable and efficient but also offers a superior sightseeing experience, allowing passengers to immerse themselves in the beauty of their surroundings. Get ready to explore new destinations in style and comfort with this exceptional electric sightseeing bus.

New Energy 22 Seats Electric Sightseeing Bus Car With Closed Door deatil (1)w5b

Led Light

The new energy 22 seats electric sightseeing bus car with closed door is equipped with LED lights that offer bright and energy-efficient illumination. These lights provide excellent visibility, ensuring safety during nighttime operations. With long lifespan and low maintenance, they add to the vehicle's reliability.

22 Seater Lithium Battery Sightseeing Bus (4)5ey

Steering Wheel

The steering wheel of the new energy 22 seats electric sightseeing bus car with closed door provides precise control and a comfortable grip. Designed with ergonomic features, it allows for easy handling, enhancing the driving experience. Made of high-quality materials, it offers durability and reliability for a safe journey.

Seat

The new energy 22 seats electric sightseeing bus car with closed door features a single seat for the main driver, while the back offers opposite seating. This design provides a clear view for the driver and allows for efficient space utilization. It offers a comfortable and convenient seating arrangement for passengers.

Tire

The tires of the new energy 22 seats electric sightseeing bus car with closed door offer excellent grip and stability. They are designed to handle the weight of the bus while ensuring a smooth and comfortable ride. Made with high-quality materials, these tires are durable and can withstand various road conditions for a safe and reliable driving experience.
