2 Seater Electric Golf Cart
product detail
Applications
- Golf Courses: The primary application of the 2 seater electric golf cart is on golf courses. It provides a convenient and environmentally friendly way for golfers to travel between holes, carrying their clubs and other equipment.
- Resorts and Communities: Many resorts and residential communities use these carts for short-distance transportation within their premises. They can be used to transport guests or residents to different areas of the resort or community, such as the pool, clubhouse, or tennis courts.
- Industrial and Commercial Use: In some industrial and commercial settings, the 2 seater electric golf cart can be used for light-duty transportation tasks. For example, it can be used in large warehouses or factories to transport small items or personnel between different work areas.
| Vehicle Overview | Vehicle Type | 2022KB(2 seats) |
| Rated Occupant | 2 People | |
| Overall Dimension | 2450x1350x2000mm (L * W * H) | |
| Maximum Speed | 40km/h | |
| Climbing Ability | 25% | |
| Curb Weight | 400kg | |
| Front and Rear Wheel Base | 1020/1070mm | |
| Wheelbase | 1705mm | |
| Minimum Ground Clearance | 180mm | |
| Braking Distance | ≤4m | |
| Minimum Turning Radius | 3.1 m | |
| Electrical Parameter | Battery | 72V 100Ah Lithium Iron Phosphate |
| Controller | 72V 350A AC Electric Control | |
| Electric Machine | 72V 5.0kw AC Motor | |
| Charger | 72V Car Intelligent Charger, Charging Time 7-8 Hours | |
| Lights and Signals | LED Combined Headlight, Combined Rear Taillight, Electric Horn | |
| Sound | 10-inch Car Multimedia, Hi-Fi Speakers, Reversing Video, Mobile Interconnection Mapping | |
| Switch | Start Switch, Light Combination Switch, Shift Switch, USB Socket (1 Type A and 1 Type C Jack) | |
| Appearance | Digital LCD Instrument (Including Voltage, Current, Speed, Mileage, Light, Front and Back Commutation Signals) | |
| Speed and Advance Control | Electronic Throttle, Switch Type Forward and Backward Direction Conversion, Stepless Speed Regulation System, Slope Anti-slip Control | |
| Vehicle Parameters | Seat | Front Seats (Leather Fabric + High Rebound PU, Middle Diamond Lattice Shape, Black and White Thread) |
| Car Body and Frame | High Strength Steel Mechanism Welded Chassis Frame, Pickling Phosphating Electrophoresis Rust Prevention + Electrostatic Powder Treatment + (Armor Spraying) | |
| Vehicle | High Strength Steel Frame and The Whole Car Injection Molding Parts, Anti-slip Floor, Paint Process | |
| Windshield and Rearview Mirror | Folding Plexiglass, Wide Field of View Manual External Rearview Mirror + Visual Turn Signal | |
| Safety Belt | Two-point Crinkle Seat Belt | |
| Chassis Parameter | Steering System | Sports Carbon Fiber Grain Steering Wheel, Efficient Rack and Pinion Type with Gap Compensation Direction Machine |
| Front Axle and Suspension | Double A-arm Independent Suspension + Shock Absorbing Spring | |
| Rear Axle and Suspension | Towing Arm Type Non-independent Suspension + Lateral Stabilizer Bar + Shock Absorbing Spring | |
| Brake System | Front and Rear Disc Brake, Double Circuit Hydraulic Driving Brake, Holding Brake Parking | |
| Tyre | 23x10.5-12 Vacuum Tires (Optional Road Tires, Off-road Tires), Aluminum Alloy Wheels | |
| Optional Configuration | Guard Bar | Front Bumper |
| Tyre | 14 "Aluminum Ring + Vacuum Tires (Optional Road Tires, Off-road Tires) | |
| Headrest | Headrest, Middle Diamond Lattice Shape | |
| Custom | Body, Seat Color |
